Principales caracteristicas tecnicas

• RF frequency

50 MHz to 2 GHz

• LO input at 2xfLO

100 MHz to 4 GHz

• IIP3 +30 dBm
• Input P1dB +13 dBm
• NF 13.5 dB @ 450 MHz
• Voltage conversion gain 4 dB

• Quadrature demodulation accuracy

Phase accuracy ~ 0.5°
Amplitude balance ~ 0.1 dB

• LO input - 10 to 5 dBm
• Demodulation bandwidth ~ 240 MHz
• I/Q drive 2 Vpk-pk into 200 Ω
• Programmable power consumption
