Norwood, MA - Analog Devices
is introducing the first precision dual operational amplifier optimized for low-noise performance in applications
operating at +2.7 V to +5.5 V. For designers of low-voltage instrumentation, audio, communications and medical
systems that require more than one precision amplifier, the AD8656 is the dual version of ADI’s recently
announced AD8655, which specifies up to two-thirds less noise than competing solutions. The AD8656 offers the
low-noise performance advantages of the AD8655, along with the board space reduction and cost savings of a dual
Precision Performance, Low Noise and DistortionApplications
The AD8656 CMOS amplifier delivers precision offset voltage performance of 250 microvolts max over the full
common-mode voltage range. The device offers low noise of 2.7 nV/rt Hz at 10 kHz and low distortion of 0.0008
percent, eliminating the need for external transistor stages or multiple parallel amplifiers to reduce system level
noise. High accuracy without system trimming is achieved through ADI’s DigiTrim™ in-package trim
technology. The ability to swing rail-to-rail at the input and output enables designers to buffer ADC
(analog-to-digital converter) inputs, DAC (digital-to-analog converter) outputs, and other wide output swing devices
in single-supply systems.
Fully specified over the –40 degrees C to +125 degrees C temperature
range, the AD8656 features 28 MHz bandwidth and offset voltage drift of 0.4 microvolts/degree C typical and 2.3
microvolts/degree C max.
Excellent noise performance and low-voltage operation makes the AD8656 well-suited for a
variety of industrial, communications, consumer and medical applications. Low distortion and fast settling time
allows the AD8656 to drive high precision ADCs such as ADI’s AD7685, maintaining the accuracy needed in
industrial and instrumentation applications, including data acquisition and test equipment systems. For consumer and
audio applications, the combination of low distortion, wide dynamic range and high output current is ideal for
microphone pre-amps, filters and line input buffering.
Availability and Pricing
AD8656 low-noise dual amplifier is available now and is priced at $1.10 per unit in 1,000 piece-quantities. It is
packaged in both 8-lead MSOP and 8-lead SOIC.
