Norwood, MA - Analog Devices’ is introducing a new single-phase, high-current
switching controller ideal for applications that demand regulated precision and reliability, such as wireless base
stations and network computing systems. The ADP1822 is a synchronous, fixed-frequency switching controller well
suited for high current applications – such as communications infrastructure systems and high performance servers.
A critical need for designing to meet power management requirements is how best to manage multiple power
sources. The ADP1822 output voltage can track an input voltage when multiple power rails sequencing is required.
This regulated output can be dynamically adjusted up or down with the regulator’s margining–control
inputs. Margining offers the capability to offset the regulated output voltage by a few percent when the system
reliability is being checked.
device operates from a 3.0 V to 5.5 V supply, and its wide voltage range of 1.0 V to 24 V provides flexibility for
designers developing higher voltage applications. Additional features include programmable soft-start, power good
indicator, shutdown, thermal overload protection, over-voltage protection and under voltage
High Power and Precision
The ADP1822 drives an all
N-channel power stage to regulate an output voltage as low as 0.6 V with 20 A load current. The controller features
a +/1 percent 0.6 V on-board voltage reference, making it ideal for next generation DSPs, FPGAs, core supplies and
microprocessors, which require a low and accurate power supply voltage under 1 V. The ADP1822 works particularly
well with Analog Devices’ embedded processors
Availability and Pricing
The ADP1822 is available now in a 24-lead QSOP
(small outline package) at $1.80 per unit in 1,000-unit quantities. and is offered over the extended industrial
temperature range of –40 degrees C to +85 degrees.
