Norwood, MA - Analog Devices Inc.
introduced a new generation of 16-bit and 18-bit PulSAR® analog-to-digital converters (ADCs) that address the
industrial customer’s need for more efficient and cost-effective data conversion, while reducing design complexity
and setting new standards for performance. SAR (successive-approximation register) converters comprise the majority
of the ADC market and are often the most cost-effective technology for applications that require very precise
digital modeling of analog signals, such as data acquisition, and process control systems used in factory
Featuring software selectable analog input ranges across multiple selections of unipolar and
bipolar ranges, the new ADCs eliminate the need for expensive level shifting and gain stages in front-end analog
circuitry, resulting in a dramatic reduction in component costs and board space requirements. Using the ADCs’
internal registers, designers have the flexibility of switching from four different input voltage ranges ‘on
the fly’ - with zero data latency. Clocking at speeds up to 750 kSPS, devices in the 16-bit AD761x series
offer up to a 6-fold improvement in sampling rate performance over existing programmable ADCs, while the AD763x ADCs
allow more precise signal conversion at 18 bits of resolution. The combination of functionality, performance and a
50 percent smaller footprint available at half the price of competing products is unprecedented in a SAR ADC.
Data acquisition systems have traditionally relied on level-shifting and gain stages to accommodate
various bipolar and unipolar analog input ranges that are required by OEM customers. This front-end signal
conditioning method includes “boot-strapping” or register-controlled programming, which is a time
consuming and costly approach. By leveraging ADI’s patented iCMOS™ industrial process technology,
the new AD761x and AD763x PulSAR ADCs allow for the selection of unipolar input voltage ranges of 0 to 5 V and 0 to
10 V, and bipolar input voltage ranges of +/–5 V and +/–10 V.
“In data conversion, innovating for greater efficiency can be
just as important as performance, and the new ADCs deliver greater value to our customers by innovating where it
means the most for designers of industrial applications,” said Mike Britchfield, product line director,
Precision Signal Processing group, Analog Devices. “The devices were designed to address the challenges of
industrial electrical environments where efficiency, size and cost are critical factors, while also passing along a
lower cost of ownership.”
More about the AD761x and AD763x PulSAR ADCs
The AD761x and
AD763x join Analog Devices’ industry leading PulSAR family of SAR converters, an ADC architecture that
provides the added advantage of zero data latency, a critical factor in data acquisition systems. The AD761x series
provide fast sampling rates at 250 kSPS to 750 kSPS combined with the high accuracy of 2.0-LSB typical integral
nonlinearity (INL). With 18-bit accuracy, the AD763x series offers the highest precision in a software programmable
ADC, with sampling rates of 250 kSPS to 670 kSPS and 2.5-LSB typical INL. The devices have very low power
consumption featuring 75mW at 500ksps.
Both the AD761x and AD763x integrate a complete range of
analog functions on-chip, including an internal 2.5 V reference, an internal conversion clock, error correction
circuits, and both serial and parallel interfaces. The ADCs are pin-compatible with other parts within their
The 16-bit AD761x PulSAR ADCs can be coupled with ADI’s new ADR12x low
power voltage references, which offer the highest accuracy over the extended industrial temperature range of
-40 to +125 degrees C, within a tiny TSOT-23 package.
Availability and Pricing
Both the new 16-bit PulSAR ADC series (AD7610 and AD7612) and the 18-bit PulSAR ADC series (AD7631 and
AD7634) are sampling now, with full production slated for December 2005. The 16-bit devices are available at prices
starting at $12.90 per unit for the AD7610; and the 18-bit devices are available at prices starting at $25.10 per
unit for the AD7631, in 1,000-piece quantities. Both series of devices are available in 48 lead LQFP (leaded quad
flat pack) and 48-lead LFCSP (lead frame chip-scale package) packaging.
