BC160, 161
PNP Medium Power Transistors
Page 1
31/05/05 V1.0
Features:
• PNP Silicon Power Switching Transistors.
• Medium Power Amplifier and Switching Applications.
Dimensions: Millimetres
Dimension
Minimum
Maximum
A
8.50
9.39
B
7.74
8.50
C
6.09
6.60
D
0.40
0.53
E
-
0.88
F
2.41
2.66
G
4.82
5.33
H
0.71
0.86
J
0.73
1.02
K
12.70
-
L
42
°
48
°
TO-39 Metal Can Package
Pin Configuration:
1. Emitter
2. Base
3. Collector
BC160, 161
PNP Medium Power Transistors
Page 2
31/05/05 V1.0
Junction to Ambient in Free Air
R
th(j-a)
219
°C/W
Junction to Case
R
th(j-c)
44
Thermal Characteristics
Description
Symbol
BC160
BC161
Units
Collector Emitter Voltage
V
CEO
40
60
V
Collector Base Voltage
V
CBO
Emitter Base Voltage
V
EBO
5.0
Collector Current - Continuous
I
C
1.0
A
Power Dissipation at T
a
= 25 ºC
Derate Above 25 ºC
P
D
0.8
4.57
W
mW/ °C
Power Dissipation at T
c
= 25 ºC
Derate Above 25 ºC
4.0
22.73
Operating and Storage Junction
Temperature Range
T
J
, T
stg
-65 to +200
°C
Absolute Maximum Ratings
BC160, 161
PNP Medium Power Transistors
Page 3
31/05/05 V1.0
Description
Symbol
Test Condition
Minimum Typical
Maximum
Units
Collector Emitter Voltage
V
CES
I
C
= 100
µA, V
BE
= 0
BC160
BC161
40
60
-
-
V
Collector Emitter Voltage
*V
CEO
I
C
= 10mA, I
B
= 0
BC160
BC161
40
60
-
-
Emitter Base Voltage
V
EBO
I
E
= 100
µA, I
C
= 0
5
-
-
Collector Cut off Current
I
CES
V
CE
= 40V, V
BE
= 0,
BC160
V
CE
= 60V, V
BE
= 0,
BC161
Ta = 150 ºC
V
CE
= 40V, V
BE
= 0,
BC160
V
CE
= 60V, V
BE
= 0,
BC161
-
-
100
100
100
100
nA
µA
DC Current Gain
*h
FE
I
C
= 100mA, V
CE
= 1V
BC160/BC161
Group-6
Group-10
Group-16
I
C
= 1A, V
CE
= 1V
BC160/BC161
Group-6
Group-10
Group-16
40
40
63
100
26
15
20
30
400
100
160
250
-
Collector Emitter Saturation Voltage
*V
CE(sat)
I
C
= 1A, I
B
= 0.1A
-
-
1.0
V
Base Emitter on Voltage
*V
BE(on)
I
C
= 1A, V
CE
= 1V
-
-
1.7
Dynamic Characteristics
Transition Frequency
f
T
I
C
= 50mA, V
CE
= 10V, f = 20MHz
50
-
-
MHz
Output Capacitance
C
ob
V
CB
= 10V, I
E
= 0, f = 1MHz
-
-
30
pF
Input Capacitance
C
ib
V
EB
= 10V, I
C
= 0, f = 1MHz
-
-
180
Switching Characteristics
Turn On Time
t
on
I
C
= 150mA, I
B1
= 5
µA
-
-
500
ns
Turn Off Time
t
off
I
C
= 100mA, I
B1
= I
B2
= 5
µA
-
-
650
Electrical Characteristics (T
a
= 25 ºC unless specified otherwise)
*Pulsed : Pulse Duration
≤300 µs, Duty Cycle ≤1%
BC160, 161
PNP Medium Power Transistors
Page 4
31/05/05 V1.0
Package
Part Number
TO-39
BC160-6
BC160-10
BC160-16
BC161-6
BC161-10
BC161-16
Specifications
For enquiries from all other markets
BC160, 161
PNP Medium Power Transistors
Page 5
31/05/05 V1.0
Notes:
